Cummins power
generating sets
500KVA /400kw generating sets KTA19-G4-50Hz
use:Land
Frequency Hz:50Hz
DK Model::DK440
Product Name:400kw generating sets -50Hz
Model:KTA19-G4
Prime Power(kw/Kva):400/500
Standby Power(kw/Kva):440/550
Rated Current A:772
Open type Dimension(L*W*H) mm:3600*1366*1830
Open type Weight Kg::4000
Manufacturer:Cummins
Model:KTA19-G4
Exhaust：19
Continuous/Standby（KW):448/504
Aspiration & Cooling:Turbo/Aftercooled
Cylinders Capacity Lt :6
Cylinders & Build :In line
Speed RPM :1500
Bore & Stroke mm×mm :159×159
Compression Ratio:13.9
Governor :EFC
Fuel consumption g/kw.h :196
Fuel consumption（L/h）:110
Lub-oil Capacity Litre ：50
max oil temperature （℃）：121
Coolant Capacity Litre ：91
Max intake resistance（kPa)：6.2
Max exhaust back pressure：10
Flue gas temperature （℃）：528
Thermostat（℃）：82-93
Stamford :HCI544D
Output Voltage V :：400/230
Steady Voltage Adjusting Range:±1%
Insulation：H
Protection：IP23
Ventilation cooling capacity（1/s)：1050
Rated capacity（V)：24
