Cummins generator set
generating sets
413/375KVA generating sets NTAA855-G7-50Hz
use:Land
Frequency Hz:50Hz
DK Model::KC330
Product Name:413/375KVA generating sets -50Hz
Model:NTAA855-G7
Prime Power(kw/Kva):300/375
Standby Power(kw/Kva):330/413
Rated Current A:541
Open type Dimension(L*W*H) mm:3500*1150*1770
Open type Weight Kg::3290
Manufacturer:Cummins
Model:NTAA855-G7
Exhaust：14
Continuous/Standby（KW):343/377
Aspiration & Cooling:Turbo/Aftercooled
Cylinders Capacity Lt :6
Cylinders & Build :In line
Speed RPM :1500
Bore & Stroke mm×mm :140×152
Compression Ratio:15.1
Governor :EFC
Fuel consumption g/kw.h :204
Fuel consumption（L/h）:84
Lub-oil Capacity Litre ：36.7
max oil temperature （℃）：121
Coolant Capacity Litre ：63
Max intake resistance（kPa)：6.2
Max exhaust back pressure：10
Flue gas temperature （℃）：485
Thermostat（℃）：82-93
Alternator Stamford:HCI444FS
Output Voltage V :：400/230
Steady Voltage Adjusting Range:±1%
Insulation：H
Protection：IP22
Ventilation cooling capacity（1/s)：486
Rated capacity（V)：24
